MDR 1
Single phase
Switching capacity 4.0 kW
250 Volt 50/60 Hz / 20 Amp MAX. IP 44
MAX. cut-out pressure 11 bar
Incl. cable glands PG 11 Z /ZK
2 poles (N.C.)
Acc. to EN 60947
Differential adjustment
ON REQUEST WE SUPPLY ALSO DIFFERENT MODELS.
Art. 127/1C
| - Pressure: 11 bar
- Factory pressure adjustement: 6-8 bar
- Flange: G.1/4" 1 WAY
- Version: EURO-standard with screw terminals
- Unloader valve: AEV 1S delayed quick connect Ø6
- Overload relay: Without overload relay
- Other details: Standard diaphragm. ON/OFF manual switch
| |
Art. 127/2CA
| - Pressure: 11 bar
- Factory pressure adjustement: 7-9 bar
- Flange: G.1/4" 4 WAYS
- Version: EURO-standard with screw terminals
- Unloader valve: AEV 1S delayed quick connect Ø6
- Overload relay: Without overload relay
- Other details: Standard diaphragm. ON/OFF manual switch
| |
Art. 127/6C
| - Pressure: 11 bar
- Factory pressure adjustement: 6-8 bar
- Flange: G.1/4" 4 WAYS
- Version: EURO-standard with screw terminals
- Unloader valve: EV 1S quick connect Ø6
- Overload relay: Without overload relay
- Other details: Standard diaphragm. ON/OFF manual switch
| |
Art. 127/2CC
| - Pressure: 11 bar
- Factory pressure adjustement: 7-9 bar
- Flange: G.1/4" 4 WAYS
- Version: EURO-standard with screw terminals
- Unloader valve: EV 1S quick connect Ø6
- Overload relay: Without overload relay
- Other details: Standard diaphragm. ON/OFF manual switch
| |
